Data Centers and AI

Shapes for planning, building and explaining data centers and AI computing: racks and servers, GPUs and AI clusters, networking and storage, cooling, power and the data hall, plus diagrams of how AI models are trained and served. Includes 80 illustrations, half flat and half isometric. All informal illustrations, not vendor products or engineering symbols.

80 shapes · Free · For SimpleDiagrams 5 for Mac

Ethernet Cable

ethernet cable, rj45, patch cable, copper, network cable

Rack Cable Management

cable management, finger duct, patch cords, rack, cable dressing

Overhead Cable Tray

cable tray, ladder tray, overhead cabling, cable ladder, data centre

Storage Array

storage array, san, disk shelf, enterprise storage, data storage

Network Attached Storage

nas, network attached storage, file server, drive bays, storage

Tape Library

tape library, tape backup, lto, archive, robotic library

Hard Disk Drive

hard disk drive, hdd, hard drive, platter, storage

NVMe SSD

nvme ssd, m.2, solid state drive, flash storage, ssd

Object Storage

object storage, storage bucket, blob storage, metadata tags, cloud storage

Backup and Restore

backup, restore, data protection, disaster recovery, schedule

Data Replication

data replication, replica, disaster recovery, mirroring, data centre

Internet Uplink

internet uplink, wan link, isp, redundant links, edge router

Data Hall

data hall, white space, server room, data center, data centre

Hot and Cold Aisles

hot aisle, cold aisle, airflow, raised floor, data centre

Aisle Containment

aisle containment, cold aisle containment, hot aisle, enclosure, data centre

Raised Floor

raised floor, floor tile, pedestal, plenum, perforated tile

Colocation Cage

colocation, colo cage, cage, secure space, data centre

Computer Room Air Handler

crah, air handler, crac, cooling unit, precision cooling

In-Row Cooler

in-row cooler, in-row cooling, close-coupled cooling, chilled water, rack cooling

Rear-Door Heat Exchanger

rear door heat exchanger, rdhx, cooling door, liquid cooling, rack cooling

Coolant Distribution Unit

cdu, coolant distribution unit, liquid cooling, pump, heat exchanger

Immersion Cooling Tank

immersion cooling, immersion tank, liquid cooling, dielectric fluid, tank

Uninterruptible Power Supply

ups, uninterruptible power supply, battery cabinet, backup power, power

Overhead Busway

busway, busbar, tap-off box, rack power, power distribution

Direct-to-Chip Cold Plate

cold plate, direct-to-chip, liquid cooling, microchannel, chip cooling

Environmental Sensor

environmental sensor, temperature sensor, humidity, rack monitoring, probe

Access Control Reader

access control, card reader, badge, security door, fingerprint

Monitoring Dashboard

monitoring, dashboard, dcim, floor map, hot spot

Data Center Technician

data center technician, technician, remote hands, server, data centre

Network Engineer

network engineer, engineer, laptop, console cable, networking

Virtual Machines

virtual machines, vm, hypervisor, virtualization, virtualisation

Containers

containers, containerization, container runtime, microservices, workloads

Download library

Library: Data Centers and AI

Version: 1

Free. No card needed. New here? Create an account, it takes a minute.

What you need to use this

SimpleD, of course. These shapes work in SimpleDiagrams 5 for Mac. Don't have it yet?

Get SimpleDiagrams

How to install

Download the library .zip and unzip it. The .sdlibrary file is inside. Then:

Double-click the .sdlibrary file to automatically install it into SimpleDiagrams.
Drag and drop the .sdlibrary file anywhere in a SimpleDiagrams document window.
Open the Library panel menu in SimpleDiagrams and choose "Import Library…", then pick the .sdlibrary file.

About updates

If you install a newer version, SimpleDiagrams will ask before replacing the library you have. This package is signed. A compatible version of SimpleDiagrams verifies the signature before showing it as an official library.

SHA-256 checksum, for anyone who wants to check the download.

4b9eac37af990e5c9ed375e1df3a7829a9eab5e22ae781e41483d070698ee0e6

Licence

Free to use in your own diagrams, including commercial work, under the Service and Shape Licence. Please don't pass the library on; send people here instead.
