Solar & Battery Sites
Sketch solar PV and battery storage sites, from panels and DC collection through inverters, battery systems, grid connections and site operations. Includes 80 hand-drawn illustrations for informal planning and communication.
Important: These shapes are for informal planning, presentations and communication only. They are not standardised electrical symbols and are not intended for electrical schematics, engineering specifications, installation or maintenance instructions, or compliant safety signage. Illustrations do not establish that a system is safe or meets applicable standards.
80 shapes · Free · For SimpleDiagrams 5 for Mac
